Compact Seal 1H6

Fabric compact seal for medium-duty hydraulic applications.

Application Range
Pressure: ≤ 250 bar
Temperature: -30 °C / +100 °C
Sliding Speed: ≤ 0,5 m/s
Standard Material: 0001K

Other materials are available for very high or very low operating temperatures. For detailled information, please look at the specific PDF catalogue or contact our application engineers.

Load product catalog

Are you missing materials or dimensions?

Feel free to contact us!

Our sealing experts will be happy to advise you!

+49(201)86606-0 or vk@techno-parts.de

Filter

d [mm] D [mm] H [mm] L [mm]
Min:
Max:
Material selection
Material:
Material No.
Profile d [mm] D [mm] H [mm] L [mm] Material Mat. No. V Quantity
