PTFE shaft seal WP2

PTFE shaft seal with metal case, with two sealing lips for higher pressures. Other materials are available for very high or very low operating temperatures (see PDF Catalogue or contact our application engineers).

Application Range

Pressure: ≤ 35 bar
Temperature: -20 °C / +250 °C
Sliding Speed: ≤ 3 m/s
Standard Material: PTFE-comp. (metal case)

Load product catalog

Are you missing materials or dimensions?

Feel free to contact us!

Our sealing experts will be happy to advise you!

+49(201)86606-0 or vk@techno-parts.de

Filter

Di [mm] Da [mm] b [mm]
Min:
Max:
Material selection
Material:
Material No.
Profile Di [mm] Da [mm] b [mm] Material Mat. No. V Quantity
